Power and processing:
- 9-channel amplifier
- 105 watts per channel into 8 ohms (20-20,000 Hz) at 0.08% THD, with 2 channels driven
- Dolby® and DTS® surround sound decoding
- Dolby Atmos® processing for use with in-ceiling or “height” speakers for more enveloping home theater sound
- Dolby Atmos Height Virtualization and DTS Virtual:X® create three-dimensional effects without height speakers
- IMAX® Enhanced reproduces the full dynamic range of specially encoded IMAX soundtracks from compatible sources
- Audyssey speaker calibration and system optimization includes:
- MultEQ® XT32 auto setup and room calibration delivers balanced, dynamic sound with enhanced surround performance
- Dynamic Volume anticipates loud sounds to keep volume levels even
- Dynamic EQ improves dialogue, bass response, and surround channel levels at lower volumes
- Sub EQ HT provides individual calibration for dual subwoofers, for even bass response throughout the room
- Low Frequency Containment reduces the amount of bass that bleeds into other rooms
- Audyssey MultEQ Editor app for further audio customization (paid app; not included)
Digital and streaming music options:
- built-in Wi-Fi for listening to music from a networked PC, free internet radio, and music services
- HEOS Built-in technology wirelessly connects compatible HEOS components for whole home audio
- includes support for Pandora®, SiriusXM, and Spotify® (subscription required for some services)
- free HEOS app offers easy Wi-Fi control, settings adjustments, and music selection and playback
- works with Amazon Alexa and Google Home voice control assistants
- Apple AirPlay 2 lets you stream directly from an iPhone® or iPad® and ask Siri to play Apple Music®
- supports multi-room audio with compatible wireless speakers
- built-in Bluetooth for wireless music listening with smartphones, tablets, and compatible computers
- Bluetooth transmission for sending audio from the receiver to Bluetooth-enabled headphones
- play audio through Bluetooth headphones only, or through Bluetooth headphones and connected speakers simultaneously
- plays high-resolution digital music files via USB storage device or a networked computer (PCM up to 24-bit/192kHz resolution; DSD up to 5.6 MHz)
- Denon’s Compressed Audio Restorer improves sound quality of MP3s and other digital music files
Multi-room audio/video:
- dual-room/dual-source output
- amp assign function lets you use surround back speaker outputs for front height, Zone 2, Front B, or bi-amping front speakers
- using powered 2nd-room output allows 7.2-channel sound in main room
- All Zone Stereo mode ensures that both zones stay in sync when playing the same source
- All Zone TV Audio lets you play surround sound in your main room and downmixed stereo in your 2nd room
- supports both analog and digital audio connections
- HDMI dual-zone switching for watching video content from different sources in two zones simultaneously
- Zone 2 compatible audio sources: HDMI audio, optical/coaxial digital inputs, analog audio inputs, AM/FM tuner, USB, Bluetooth, and HEOS music apps
- cannot select different USB/Bluetooth/network sources for each zone
Connections:
- HDMI 2.1 audio/video switching: 7 in, 3 out
- 1 input and 2 outputs support 8K/60Hz and 4K/120Hz video
- all inputs and outputs support 4K/60Hz video
- HDCP 2.3 technology ensures compatibility with Ultra HD sources and TVs
- HDR-compatible for extended picture contrast and brightness with compatible TVs and HDR-encoded content
- supports HDR10, HDR10+, Dolby Vision™, and HLG
- gaming-optimized video processing technologies for a smooth, lag-free gaming experience
- Variable Refresh Rate (VRR), Auto Low Latency Mode (ALLM), and Quick Frame Transport (QFT) reduce or eliminate lag and frame tearing
- supports ARC (Audio Return Channel) and eARC (Enhanced Audio Return Channel)
- eARC receives uncompressed surround sound signals including Dolby Atmos and DTS:X via the HDMI connection with your compatible TV
- component video switching: 2 in, 1 out
- composite video switching: 3 in, 1 out
- digital audio inputs: 2 Toslink optical, 2 coaxial
- 5 analog stereo RCA audio inputs
- MM (moving magnet) phono input for connecting a turntable
- 11.2-channel preamp outputs
- two discrete line-level subwoofer outputs for more precise multi-subwoofer setups
- front-panel USB port for audio playback from USB flash drives
- Ethernet port for network connection
- outputs for 11 speakers (Front L/R, Center, Surround L/R, Surround Back L/R, Height1 L/R, Height2 L/R)
- receiver can power a maximum of 9 channels at once
- RS-232C, remote (IR), and 12-volt trigger connections for use with optional third-party controller
- full-sized headphone jack
- removable power cord
General features:
- free Denon AVR Remote app lets you use your Apple® or Android™ device as a Wi-Fi remote
- Setup Assistant guides you through the initial connection process and settings
- HDMI standby pass-through allows HDMI switching without powering up receiver
- intuitive, full-color on-screen guide
- AM/FM tuner
- remote control
- 17-3/16″W x 6-9/16″H x 15-15/16″D (9-5/16″H with Wi-Fi antennas raised)
- weight: 27.6 lbs.
